Prefabricated Steel Frame Warehouse Building 50-70 Year Lifespan

Brand Name : YDX

Model Number : YDX-AFG5

Certification : CE ISO SGS

Place of Origin : CHINA,QINGDAO

MOQ : 10-10000 square meters

Price : $30.00-$65.00

Payment Terms : T/T

Supply Ability : 10000 tons/month

Delivery Time : 20-30 works days

Packaging Details : Exported standard packing

Customization : Available

Structural Integrity : Excellent

Product Insulation : Thermal Insulation

Versatility : Flexible

Material : Steel

Usage : Building Construction

Type : Prefabricated Steel Frame Buildings

Product Material : Steel

Structure Type : Frame

Frame Type : Steel Frame

Earthquake Resistance : Strong

Windows : Aluminum

Seismic Design : High Seismic Zone

Installation Time : Short

Aesthetics : Modern

Construction Type : Frame

Cost : Moderate

Product Resistance : Corrosion Resistant

Finish : Galvanized/Painted/Cladding

Roof : Glass Wool, EPS, PU

Product Fire Resistance : Fireproof

Door : Sliding Door or Rolling Door

Contact Now

Multi Functional Metal Warehouse Buildings Prefabricated Z Purlin

1.Product Usage Filed:

Prefabricated Steel Structure are used for diverse applications such as Warehouse; Workshop; Factory; Cold storage building; High-rise building; Shopping mall; Power plants; Distribution centers; Pedestrian bridge; Steel structure hotels; Prefabricated public schools; Sports arenas & sports hall; Car parking center; Airplane hangars & aviation hangars; Church building & Community center; Poultry farm; Agricultural building & barns; Storage shed; Self-storage building; Green house; Garage; Commercial building; Industrial building and many more.

2.Advantages of Steel Structure Building

Cost-effective

Compared to other framing materials, structural steel brings greater value to a project in terms of initial cost as well as reduces costs in other areas.

Accelerated schedules

Structural steel is fabricated off-site while preliminary site preparation and foundation work are being performed. It is then brought to the site and rapidly erected, accelerating the overall project schedule.

Quality

Structural steel is fabricated off-site under controlled conditions, ensuring a high-quality product and reducing the number of costly fixes at the job site.

Recycling

Today's modern steel mills produce steel containing an average of 90% recycled material. At the end of a building's life cycle, 100% of the steel frame can be recycled.

Safety

By using prefabricated building solutions construction time is significantly shorter, meaning less time and fewer reasons for accidents to occur.

Future Adaptability

Steel buildings and frames are easily expanded either upwards or to any side. Because steel is extremely strong for its weight it can support the added weight of new stories.

3. Product Specifiactions

Product Application
Light Frame Steel Construction Hangar Design Prefabricated Steel Structure Factory Building Workshop warehouse
A pre-engineered steel building is a modern technology where the complete designing is done at the factory and the building components are brought to the site and then fixed/jointed at the site, all is bolt connection, no need any welding!
An efficiently designed pre-engineered building can be lighter than the conventional steel buildings by up to 30%. Lighter weight equates to less steel and potential price savings in structural framework.
SPECIFICATION FOR STEEL STRUCTURE BUILDING
Main Steel Frame	Steel Column & Beam	1. Material: Q345B (S355JR) or Q235B(S235JR)/ Welded/Hot Rolled H section steel
		2. Surface: Hot Dip Galvanized or Painted;
		3. Connection: All Bolts Connection;
Supporting System	Roof Purlin	C or Z Section Steel, Q235B
	Wall Purlin	C or Z Section Steel, Q235B
	Bracing	Steel Rod, Q235B
	Cross Support	Steel Rod, Q235B
	Column Support	Angle Steel; Steel Rod; Q235B
	Angle Brace	Angle steel,Q235B
	Tie Bar	Steel Pipe,Q235B
	Roof & Wall System	1. Single Colorful Corrugated Steel Sheet; Thickness: 0.3-0.8mm
	Roof & Wall System	2. Sandwich Panel with EPS, Rock Wool, Fiberglass,PU; Thickness: 50-150mm;
Accessories	Door	Sliding; Rolled Up Door (Manual/Auto)
	Window	Aluminum Alloy; PVC;
	Downspout	PVC pipe;
	Gutter	Galvanized Steel Sheet; Stainless Steel
	Ventilator	Stainless Steel Turbine Ventilator
	Skylight Belt	FRP or PC semi-transparent Skylight Belt
	Flash	Color Steel Sheet
	Fittings	Anchor Bolt; High Strength Bolt; Standard Bolt, Self-tapping nail etc

Prefabricated Steel Frame Warehouse Building 50-70 Year Lifespan

Steel structure building
1. Primary Framing		Box beam column, cross steel column, H-shaped steel column, steel beam
2. Secondary Framing		Galvanized Z and C sections purlin
3. Roof and Wall panels		Steel sheet and insulated sandwich panels (EPS, fiberglass wool and PU).
4. Steel Decking Floor		Galvanized steel decking board
5.Structural subsystem		Divider, gutter, awning, partition wall
6.Mezzanines, Platforms		Painted or galvanized H beam
7.Other Building Accessories		Sliding doors, roll up doors, aluminium windows, louvers, etc.
Service Life	50-70years		support	steel angle, steel pipe, steel round
Place of Origin	Qingdao,Shandong,China		Application	workshop, warehouse, poultry house,garage etc
Grade	Q235B, Q355B or as per customer's need		Bolt Grade	M20, M16, M14 etc
Connection	intensive bolt, ordinary bolt		Window	PVC steel or aluminum alloy
Downspout	PVC pipe or as per customer's request		Door	sliding or rolling door
Purlin	C/Z shape profile		Panel	EPS/PU/fiber glass/rock wool
Main Frame	Welded or hot rolled H-shaped steel, columns, beams, box beams and columns
Drawings & Quotation:
(1) Customized design is welcomed.
(2) In order to promise an accurate quotation and drawings, please let us know the length, width, eave height and local weather.We will quote for you promptly.

Packing & Loading:

Prefabricated Steel Frame Warehouse Building 50-70 Year Lifespan

Why Choose Our Steel Structures?

"Quality first, Customer first" is our company principle. We have earned an excellent reputation through our commitment to quality and service, while fostering teamwork and win-win cooperation with our clients.

Cost-effective: Professional design reduces construction time and material costs
Eco-friendly: Specialized cladding materials provide superior acoustic and thermal insulation; recyclable materials
Comfortable design: Spacious interiors with wide bays offer excellent visibility and functionality
Durable construction: 50-year service life with proper maintenance
Custom solutions: Flexible designs to meet specific industrial requirements

The following question we need to know before making the price. Just feel free to fill what you know.

1	Location (where will be built?)	_____country, area
2	Size: lengthwidthheight	_____mm_____mm_____mm
3	wind load (max. wind speed)	_____kn/m2, _____km/h, _____m/s
4	snow load (max. snow height)	_____kn/m2, _____mm
5	anti-earthquake	_____level
6	brickwall needed or not	If yes, 1.2m high or 1.5m high
7	thermal insulation	If yes, EPS, fiberglass wool, rockwool, PU sandwich panels will be suggested; . if not, the metal steel sheets will be ok. The cost of the latter will be much lower than that of the former
8	door quantity & size	_____units, _____(width)mm*_____(height)mm
9	window quanity & size	_____units, _____(width)mm*_____(height)mm
10	crane needed or not	If yes, _____units, max. lifting weight____tons; max. lifting height _____m
